Semi Conducting Black Crepe Paper
Semi conducting black crepe paper is used by transformer industries as well as cable covering industries.
Features:
Made from paper, this product offers superior conductivity, high strength, high-temperature tolerance and bio-degradable properties compared to the man-made materials used as a base.
Application:
The main application of this material is to ground the leakage of current in transformers and cables alike.
Availability:
The base papers used are 50 GSM and 80 GSM having high strength characteristics. • Standard Thickness: 0.30 mm and 0.50 mm.
Available in roll form of the maximum width of 40"(1000 mm) or in slit widths – 15 mm onwards.
Features: Made of Electrical Grade Insulation Crepe Kraft Paper, these tubes can withstand 360o bending without collapsing. Direction of creping is transverse. These tubes have extremely good compatibility with liquid di-electrics. The Tube retains maximum oil due to use of Crepe Paper. These tubes can bend under extreme conditions without collapsing. 105oC for EGI Brown and 120oC for EGI TU Green Crepe Tubes.
Class "A" insulation.
Availability:
ID. starting from 2 mm. O.D. / Wall Thickness as per specification.
Standard length is 1000mm / 2000mm.
Any length up to 2000mm available as per customer specification.
Tolerances:
I.D. + 0.5mm. • O.D. + 1.0mm
